15kg Light Track GB11264 89 Standard Steel Products Track Light Rail



chinacoal11
www.chinacoalintl.com
m.chinacoalintl.com
we provide service of enterprise's customs declaration, inspection.
15kg light track, light track, rail light

Product Introduction

GB light crane rail 15kg track rail light
Light Rail 15kg/m
Standard:GB11264-89
Material:Q235,Q235B,50Q,55Q
Weight:15.20kg/m
Length:6m,8m,9m,10m,12m,etc
Products with the features of high level purity, precise chemical composition control, high dimensional accuracy and excellent surface quality,the products are mainly used in railway, tunnel, crane,etc.
Main standards: Q/YY001-2008,Q/YYG002-2008,
                          GB2585-81,GB11264-89,GB2585-2007,
                          YB222-63,YB/T5055-93,TB/T2344-93,TB/T2635-2004,
Main grades: Q235,Q235B,50Q,55Q
                     45Mn,50Mn,U71Mn,U71,U75V,U75VM,PG4
                     BS700,BS900A,UIC900A,UIC1100,
                     EN grades, AREMA grades

Main Parameter

Name of Commodity
Specificaton
Materials  (Steel Grade)
Standard of Products
Theory Weight (kgs/M)
Length of Dimension    (M)
Packed In Bundle With Iron Wire (pcs/bundle)
Light Rail
4kgs/m
Q235
Q/YYG001-2008
4kgs/m
6,8,9,10
75
8kgs/m
Q235
Q/YYG001-2008
8.42kgs/m
55
12kgs/m
Q235
GB11264-89
12.2kgs/m
36
15kgs/m
Q235/55Q/50Q
GB11264-89
15.2kgs/m
28
18kgs/m
Q235/55Q/50Q
YB222-63
18.06kgs/m
21
22kgs/m
Q235/55Q/50Q
GB11264-89
22.3kgs/m
21
24kgs/m
Q235/55Q/50Q
Q/YYG001-2008
24.46kgs/m
21
30kgs/m
Q235/55Q/50Q
GB11264-89
30.1kgs/m
15
